Industrial Robots / PL Series / PL80
Applications:
Palletizing, Pick and Pack, IP65-67
80.0 kg
Payload
YRC1000
Controller
2061 mm
Horizontal Reach
3291 mm
Vertical Reach
Motoman PL190 industrial robot

Extremely agile and efficient, the five-axis PL80 brings robust capability in a small size robot to the PL-series robot line. Offering a wide working range in a compact design, the PL80 features exceptionally fast axis speeds and acceleration capabilities for optimum production output. Highly reliable for case palletizing, bag palletizing, de-palletizing, layer picking and layer forming, the PL80 robot has an IP67-rated wrist and an IP54 body as standard.



Download Datasheet  Get Pricing

PL190 robot spec diagram
